IES-1081 User Manual
Page 28
Understanding the Browser Interface
The web browser interface provides groups of point-and-click buttons at the left field of the screen for
configuring and managing the switch.
SYSTEM
System Information, System Name/Password, IP Address, Save Configuration,
Firmware Upgrade, Alarm Setting, Reboot, Logout
PORT
Configuration, Port Status, Rate Control, RMON Statistics, Per Port Vlan
Activities
SWITCHING
Bridging, Static MAC Entry, Port Mirroring
TRUNKING
Port Trunking
STP / RING
Global Configuration, RSTP Port Setting, MSTP Properties, MSTP Instance Setting, MSTP
Port Setting, Ring Setting
VLAN
VLAN Mode Setting, 802.1Q VLAN Setting, 802.1Q Port Setting, Port Based
VLAN
