4 Dimensions
Figure 4. 175318PCM, 175320PCM
and 175321PCM Dimensions
J 5 02
J5
03
L1
L2
FAULT
TQ LIMIT
TQ
TB501
AC AC -
V U W
3.80 [97]
4.30 [109]
S1 S2 E
1 D
3 2 1
J MP501:INPUT RAN
GE
1:0-5VD
C
2:0-10VD
C
3 :4-
20
M
A
J MP5
02
:INPUT TYP
E
TB50
1
2-3:
C URREN
T
1-2:V
O
LTA
GE
0.97 [25]
2.72 [69]
3.70 [94]
ALL DIMENSIONS IN
INCHES [MILLIMETERS]
0.96 [24]
2.12 [54]
H
TOTAL HEIGHT (H)
(TOP OF CAP TO
BOTTOM OF CHASSIS)
175318PCM 2.03 [51.6]
175320PCM 2.68 [68.1]
175321PCM 2.48 [63.0]
E2 E1 S3 S2 S1 D
