5
Cycle Mon-Fri Saturday Sunday
1 5:00 am 5:00 am 5:00 am
82F 82F 82F
2 7:00 am 9:00 am 9:00 am
75F 75F 75F
3 5:00 pm 5:00 pm 5:00 pm
82F 82F 82F
4 10:00 pm 10:00 pm 10:00 pm
75F 75F 75F
P1 （EARLY RISER）
The thermostat has four Preset Heating Schedules P1, P2,
P3, P4 and a User Defined Programmable Mode U1. To
select one of these hold Program and use ▼ and ▲ to
select one of these.
Programing U1
1. Design your custom heating
schedule, then fill out the table
(on left) for reference while
programming U1.
2. Hold Program until it says Pro, and
then select U1. Press Program.
3. Use the ▼ and ▲ adjust the
Hour.
4. Press Program to go to Minutes
and use ▼ and ▲ to adjust.
5. Press Program again to go to
Temperature and use ▼ and ▲
adjust.
6. Press Program to go to the Sat and
repeat steps 1-5. Repeat all steps
for Sunday.
7. Press Hold/Return or wait 16
P2 (LONGER DAY)
Cycle Mon-Fri Saturday Sunday
1 5:00 am 6:00 am 6:00 am
82F 82F 82F
2 8:00 am 9:00 am 9:00 am
75F 75F 75F
3 6:00 pm 5:00 pm 5:00 pm
82F 82F 82F
4 11:00 pm 11:00 pm 11:00 pm
75F 75F 75F
Cycle Mon-Fri Saturday Sunday
1 6:00 am 6:00 am 6:00 am
82F 82F 82F
2 8:00 am 9:00 am 9:00 am
79F 79F 79F
3 6:00 pm 6:00 pm 6:00 pm
82F 82F 82F
4 10:00 pm 10:00 pm 10:00 pm
75F 75F 75F
P3 (AT HOME DURING THE DAY) P4 (TAKE THE CHILL OFF)
Cycle Mon-Fri Saturday Sunday
1 6:00 am 7:00 am 7:00 am
75F 75F 75F
2 9:00 am 10:00 am 10:00 am
70F 70F 70F
3 6:00 pm 6:00 pm 6:00 pm
75F 75F 75F
4 10:00 pm 10:00 pm 10:00 pm
70F 70F 70F
SAVE THESE INSTRUCTIONS
PROGRAMING FUNCTIONS
KING ELECTRIC MFG CO · 9131 10TH AVENUE SOUTH · SEATTLE, WA 98108 · PH:206 762 0400 · FAX: 206 763 7738 · www.king-electric.com
Cycle Mon-Fri Saturday Sunday
1
AM/PM
°F/°C
2
AM/PM
°F/°C
3
AM/PM
°F/°C
4
AM/PM
°F/°C
U1 (USER PROGRAMMABLE MODE )
F802GFCI
Thermostat
USER PROGRAMMABLE AND PRESET HEATING SCHEDULES
Preset Modes Time and
Temperature Schedules
To select a program hold the pro-
gram and use the ▼ and ▲ to
select one.
Program
Program
