King Electric SRK02 connection kit User Manual
Page 4
Rev 10.21.12
www.king-electric.com
4
10
9
8
7
Slide the black 5 1/2
” x 1/8” heat shrink tubes over the
bus wires and apply heat.
Slide the green/yellow 5 1/2
” x 1/8” heat shrink tube over
the grounding braid and apply heat.
Place the 1/2” x 1” heat shrink tube over the cable as
shown.
Slide the junction box fitting (not provided in kit) to
the end of the cable as shown.
Make sure the heat tube overlaps the outer jacket
by ½” as shown and then apply heat to shrink the.
Immediately pinch the tube with pliers between the
bus wires while it is still hot and hold for 10 seconds
11
12
