King Electric Model CKL - Manual (Page 4)

King Electrical Mfg. Co. 9131 10th Ave South, Seattle WA 98108 ph: 206-762-0400 fax: 206-763-7738
4
CK Plenum Heater
Replacement Parts List
CK Plenum Heater Replacement Parts
ITEM STOCK ORDER # DESCRIPTION WT.
1
2
3
4
5
6
7
8
9
60T11-313198 Auto Limit Control 175° .04
4000-51-E07AE15 Low Voltage Transformer 40VA 120/24
4000-09-E07K999
4000-03-E07J999
4000-51-E07K999
4000-04-E07J999
Low Voltage Transformer 40VA 208-240/24
Low Voltage Transformer 40VA 277/24
Low Voltage Transformer 40VA 380/24
Low Voltage Transformer 40VA 480/24
KBDPC50A24VCOIL Contactor 50 Amp 3-Pole 24V Coil
KBDPC40A24VCOIL Contactor 40 Amp 3-Pole 24V Coil
15SH1-309571 Fan Delay Switch
ELD-5-034 Low Voltage Terminal Block
275-3228-00 Air Intake Temperature Control
9100233Q999 Dual Speed Fan Relay
1.48
1.25
.10
.04
.30
.36
Furnace Blower Small Blower-Small use with ¼ HP Motor
Blower-Large use with ½ HP Motor
120-8T-DD-.50PP Blower-Large use with ½ HP Motor
10.8
11.8
15.1
FE1026S ¼ HP Motor 240V
FEH1026S ¼ HP Motor 480V
FE1056S ½ HP Motor 240V
FEH1056S ½ HP Motor 480V
DAO-3GJ005
DAO-3GJ007.5
DAO-3GJ010
Capacitor 5MF 370V
Capacitor 7.5MF 370V
Capacitor 10MF 370V
9.5
13.6
.30
.30
.24
Replacement Motors and Blowers
ELEMENT
kW
WT.
1.0 ELE-1KW480V
3.8
208V Part # 240VPart # 480V Part #
ELE-1KW240V
ELE-1.6KW480V 1.6
ELE-2KW480V
ELE-2.5KW480V
ELE-3KW480V
ELE-3.3KW480V
ELE-4KW480V
2.0
2.5
3.0
3.3
4.0
ELE-4.16KW480V
ELE-5KW480V
ELE-6KW480V
4.16
5.0
ELE-7KW480V
ELE-8KW480V
ELE-8.33KW480V
ELE-10KW480V
ELE-2KW240V
6.0
7.0
8.0
8.33
10.0
ELE-2.5KW240V
ELE-3KW240V
ELE-3.3KW240V
ELE-4KW240V
ELE-4.16KW240V
ELE-5KW240V ELE-5KW208V
ELE-10KW208V ELE-10KW240V
ELE-8.33KW240V
ELE-8KW240V
ELE-7KW240V
ELE-6KW240V
4.6
5.5
2007 CK.indd : 12/07
Furnace Blower Large
