A-2 SHARC EZ-Extender Manual
10 1 RJ45 8PIN
CON_RJ45 J2 TYCO 1-16609214-1
11 1 SMA XPINS
CON043 J3 JOHNSON
COMP 142-0701-201
12 2 IDC 2X1
IDC2X1 P6,P10 FCI 90726-402HLF
13 2 IDC
2PIN_JUMPER_
SHORT SJ1-2 DIGI-KEY S9001-ND
14 1 51 1/8W 5% 1206 R9 VISHAY CRCW120651R0JKEA
15 14 0.1UF 50V 10%
0805 C3-10,C12,
C14-18 AVX 08055C104KAT
16 16 10K 1/10W 5%
0805 R1-2,R5-7,
R11-12,R16 VISHAY CRCW080510K0JNEA
17 3 33 1/10W 5%
0805 R10,R13,R18 VISHAY CRCW080533R0JNEA
18 4 10UF 25V
+80-20% 1210 C1-2,C11,C13 PANASONIC ECJ4YF1E106Z
19 2 22 1/10W 5%
0805 R3-4 VISHAY CRCW080522R0JNEA
20 2 1.2K 1/10W 5%
0805 R15,R17 VISHAY CRCW08051K20JNEA
21 1 10K 1/2W 10%
RES002 R8 COPAL
ELECT CT9EW103
Ref. Qty. Description Reference
Designator Manufacturer Part Number
