INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Maintenance & Warranty Information:
The high quality and superior design of this heater will
provide years of trouble-free performance. Each year the
heater should be checked and cleaned for lint and dust
accumulation. We recommend using a soft bristled brush
such as a paint brush to assist in removing contaminants
from the heater.
Limited One Year Warranty:
King Mfg. Co. will repair or replace without charge any King
product found to be defective or malfunctioning during the
first year of purchase to the original owner.
Wiring Diagram
Dimension Chart
L2
L1
Red
Black
Red Blk
Blk
Optional Thermostat
Single Pole
Blk
Blk
Blk
Safety
Light
Terminal
Block
T N1
M2 N2
E4
Fan
Motor
M1
L
E2
E1
E3
Blk
Blk
Blk
Blk
Blk
White
White
Elements
Limit Control
Elements
Ground
SELECTION CHART
C ATALOG
N
O
.
V
OLTS
W
ATTAGE
A
MPS
EFW1220
120
2000 16.6
EFW1224 2400 20
EFW1230 3000 25
EFW2020
2420 208
240
2000 9.6
EFW2030
2430 3000 14.4
EFW2040
2440 4000 19.2
KING Electrical Mfg. Company • 9131 10th Avenue South • Seattle, WA 98108 • Ph: 206.762.0400 • Fax: 206.763.7738 • www.king-electric.com
EFW.indd : 4/08
