The Interface can be left connected indefinitely. This is particularly useful in a multi-
panel or multi-loop scenario, where several panels/loops may need soak testing
simultaneously.
Global Commands
Some control panel commands apply to all addresses on a
loop. The most recent global command is indicated in the
Global position (before address position 1) at the top left of the
Loop display screen.
An icon is shown here for each type of global command and
more details can be seen in the top status bar by holding the
mouse over the icon in the Global position.
Global Command Icons
The various icons shown in the Global position of the main Loop display screen are
explained below:
