Harrington Hoists and Cranes SHB Trolley - Manual (Page 37)

37
9.1 SHB Parts (1 to 5 Ton)
Figure No. Part Name Parts Per Hoist 1 Ton 2 Ton 3 Ton 5 Ton
1 Side Plate G Assembly 1 72CG0105112 72CG0205112 72CG0305112 74CG0505111
2 Track Wheel G 1 T3G1101010 T3G1101020 T3G1101030 T3G1101050
3 Snap Ring 4 9047115 9047120 9047125 9047135
4 Ball Bearing 4 9000702 9000704 9000705 9000707
5 Track Wheel S 3 T3P1102010 T3P1102020 T3P1102030 T3P1102050
6 Track Wheel Washer 4 MS104010 MS104020 MS104030 MS104050
7 Snap Ring 4 9047115 9047120 9047125 9047135
8 Connection Yoke C 1 72CG0109126 72CG0209126 72CG0309126 74CG1009135
9 Chain Pin 1 P1VP0509107 P1VP0639107 P1VP0809107 M3041075
10 Spring Pin 1 9148125 9148154 9148157
11 Slotted Nut 1 M2049020
12 Split Pin 1 9009412
13 Hexagon Head Bolt 1 72CG0109129 P1VN0809114 P1VN1009114 P1VN1259114
14 Slotted Nut 1 L3183008 ES088020L J1NL00110180 J1NL00110240
15 Plain Washer 2 9012521 9012521 9012521 9012521
16 Snap Ring 2 9047126 9047126 9047126 9047126
17 Pinion 1 72CG0109134 72CG0209134 72CG0309134 72CG0509134
18 Hand Wheel 1 T6G123010 T6G123010 T7GA0509123 T7GA0509123
19 Slotted Nut 1 J1NL0011012 J1NL0011012 J1NL0011012 J1NL0011012
20 Plain Washer 1 9012515 9012515 9012515 9012515
21 Split Pin 1 9009424 9009424 9009424 9009424
22 Split Pin 1 9009417-5 9009436 9009438 9009447
23 Side Plate S Assembly 1 72CG0105113 72CG0205113 72CG0305113 74CG0505112
24 Idle Sheave 2 ES1051005L ES1051020L 72CG0301142 M3051050
25 Top Idle Sheave Shaft 2 72CG0109143 72CG0209143 72CG0309143 74CG0509116
26 Spring Pin 2 9148157 9148191 91481108 91481110
27 Suspender C 1 72CG0109145 72CG0209145 72CG0309145 74CG1009134
28 Hexagon Head Bolt 1 72CG0109129 P1VN0809114 P1VN1009114 P1VN1259114
29 Slotted Nut 1 L3183008 ES088020L J1NL00110180 J1NL00110240
30 Split Pin 1 9009417-5 9009436 9009438 9009447
31 Suspender A 2 72CG0109161 72CG0209161 72CG0309161 74CG0509201
32 Suspender B 2 72CG0109162 72CG0209162 72CG0309162 74CG0509202
33 Lower Shaft 2 74SH0109563 74SH0209563 74SH0309563 74SH0509563
34 Thick Spacer (AR) MSF116010 (12) T7G116030 (4) MSF116030 (16) 74SH0509583 (8)
35 Thin Spacer (AR) MSF117010 (30) MSF117020 (24) T6G120050 (24) 74SH0509584 (22)
36 Spring Pin 4 9148110 91481124 91481170 91481170
37 Bottom Idle Sheave Shaft 2 72CG0109169 72CG0209169 72CG0309169 74CG0509207
38 Idle Sheave 2 ES1051005L ES1051020L 72CG0301142 M3051050
40 Spring Pin 4 9148157 9148191 91481108 91481111
41 Bottom Hook Assembly 1 C3BA0102001 C3BA0202001 C3BA0302001 C3BA0502001
46 Upper Shaft 2 74SH0109581 74SH0209581 74SH0309581 74SH0509581
47 Shaft Stopper Pin 4 T6G156020 MS164020 MS164030 MS164050
48 Split Pin 4 9009432 9009432 9009433 9009433
49 Thick Spacer (AR) MSF116010 (10) MSF116030 (8) MSF116030 (8) 74SH0509583 (34)
50 Fixing Spacer (AR) MSF182010 (4) MSF182020 (8) 74SG0309583 (8) -
51 Thin Spacer (AR) MSF117010 (10) MSF117020 (20) T6G120050 (22) 74SH0509584 (18)
52 Thin Spacer C 4 74CG0109853 - - -
53 Name Plate 1 72CG0109802 73CG0209802 73CG0309802 73CG0509802
54 Name Plate B 1 3007174901 3007174901 3007174901 3007174901
55 Name Plate C 1 72CG0109805 72CG0109805 72CG0109805 72CG0109805
56 Load Chain 1 LCCF005 LCCF3015 LCC3020 LCC3025
57 Hoist Hand Chain 1 HCCF005 HCCF005 HCCF005 HCCF005
58 Trolley Hand Chain 1 HCCF005 HCCF005 HCCF005 HCCF005
59 Stopper Pin 1 M3177005 M3177015 M3177020 MS164050
60 Split Pin 1 9009411 9009413 9009413 9009433
61
Canvas Chain Container
Assembly (Option)
1
72BD0105101 (4m) 72BD0105101 (4m) 72BD0205102 (4m)
72BD0105102 (7m) 72BD0105102 (7m) 72BD0305102 (7m)
Steel Chain Container Assembly
(Option)
72BA0105101 (6m) 72BA0105101 (6m) 72BA0305101 (6m) 72BA0505101 (6m)
72BA0105102 (9m) 72BA0105102 (9m) 72BA0305102 (9m) 72BA0505102 (9m)
62 Chain Container Suspender 2 72BD0109301 72BD0209301 72BD0209301
72BD0509301 (6m)
72BD0509301 (9m)
63 Container Suspender Bolt A 2 72BD0109201 72BD0209201 72BD0309201 72BD0509201
64 Container Suspender Bolt B 2
72BD0109202
(Canvas)
72BD0209202
(Canvas)
72BD0209202 (4m)
72BA0509202
72BD0309202 (7m)
72BA0109202 (Steel) 72BA0109202 (Steel) 72BA0109202 (Steel)
72BA0109202
72BD0509202
65 Slotted Nut 4 J1NL0011012 J1NL0011012 J1NL0011012 ES088020L
66 Split Pin 4 9009424 9009424 9009424 9009424
67 Spacer 2 72BD0109203 72BD0209203 72BD0309203 72BD0509203
68 Balancer 1 72BD0109402 72BD0209402 72BD0309402 74GC0509501
69 Hexagon Head Bolt 4 9093128 9093131 9093133 9093135
70 U Nut 4 J1NU00110100 J1NU00110100 J1NU00110100 J1NU00110100
71 Stopper Spacer 1 72BD0109401 72BD0209401 72BD0309401 72BD0509401
72 Stopper 2 ER1CS9041 ER1DS9041 ER1DS9041 ER1ES9041
73 Socket Bolt 2 9091249 9091250 9091251 9091252
74 Spring washer 2 9012709 9012709 9012709 9012709
75 Chain Hoist Body 1 CB005 CB015 CB020 CB025
AR = Quantities are shown in the parentheses next to part numbers.
