3.5.6 During operation the data display will exhibit illuminating or blinking data as shown in Figure 3-9.
Figure 3-9 Illuminating/Blinking Display
3.5.7 The digital display uses a seven segment character to form the specific charaters used in the display.
Table 3-4 shows the corresponding digital characters to its English eqivalent.
Table 3-4 Digital Character Key
Character
Digital
Display
Character
Digital
Display
Character
Digital
Display
Character
Digital
Display
0
0
9
9
I
ι
R
ρ
1
1
A
Α
J
ϑ
S
Σ
2
2
B
β
K
τ
T
3
3
C
Χ
L
Λ
U
Υ
4
4
D
δ
M V
ϖ
5
5
E
Ε
N
Ν
W
6
6
F
Φ
O
ο
X No Display
7 G P
Π
Y
Ψ
8
8
H
Η
Q
θ
Z No Display
3.5.8 The LED Lamp display provides trolley status. Table 3-5 shows some of the status displays.
Table 3-5 LED Lamp Display
