Harrington Hoists and Cranes Food Grade Supplement (ER2/MR2/PT) - Manual (Page 53)

53
2.4 Side Plates and Suspension Parts– 1/4 to 2 Ton
Figure
No.
Part Name
Parts
Per
Trolley
1 Ton 2 Ton
2
Side Plate G Assembly – Standard Wheels
1
3AFG010S5201 3AFG020S5201
Side Plate G Assembly – Stainless Steel
Wheels
3AFG010S5801 3AFG020S5801
3
Track Wheel G Assembly – Standard
2
MS1101010 MS1101020
Track Wheel G Assembly – Stainless Steel 35MW0105101 35MW0205101
4 Washer 2 MS104010 MS104020
5
Snap Ring – Standard
2
9047115 9047120
Snap Ring – Stainless Steel J1SS10000015 J1SS10000020
6
Side Roller Assembly – Standard
4
MR1DS1211 MR1ES1211
Side Roller Assembly – Stainless Steel 3AFG010S2211 3AFG020S2211
8 Bolt 4 J1BAE0803030 J1BAE1003535
9 Spring Lock Washer 4 J1WS07420080 J1WS07420100
10 Nut 4 J1NA00920080 J1NA00920100
12
Side Plate S Assembly – Standard Wheels
1
3AFG010S5202 3AFG020S5202
Side Plate S Assembly – Stainless Steel
Wheels
3AFG010S5802 3AFG020S5802
13
Track Wheel S Assembly – Standard
2
MS1102010 MS1102020
Track Wheel S Assembly – Stainless Steel 35MW0105102 35MW0205102
14 Washer 2 J1WB07410080 J1WB07410100
15
Snap Ring – Standard
2
9047115 9047120
Snap Ring – Stainless Steel J1SS10000015 J1SS10000020
16
Suspension Shaft Assembly – Standard
Shaft
1
3AFG010S2101 3AFG020S2101
Suspension Shaft Assembly – Nickel Plated
Shaft
3AFG010S3101 3AFG020S3101
17
Suspension Shaft – Standard
1
MSF115010 MSF115020
Suspension Shaft – Nickel Plated 3AFG010S9115 3AFG020S9115
18 Thick Spacer 3 MSF116010 T7G116030
19 Bolt 1 3AFG010S9103 3AFG020S9103
20 Slotted Nut 1 J1NL00910100
21 Split Pin 1 J1PW06025018
22 Thick Spacer L 2 MR1DS9110 MR1ES9110
24 Thin Spacer 8 MSF117010 MSF117020
25 Shaft Stopper 1 T6G156020 MS164020
26 Split Pin 1 J1PW06040020
27
Fixing Shaft – Standard
1
MR1DS9131 MR1ES9131
Fixing Shaft – Nickel Plated 3AFG010S9131 3AFG020S9131
28 Split Pin 2 J1PW06050040
30 Spring Washer 8 J1WS07420080
31 Nut 8 J1NA00920080 J1NA00920100
32 Bumper 4 MR1DS9631
33 Bumper Lug 4 3AFG010S9361 3AFG020S9361
34 Spring Washer 4 J1WS07420080
35 Nut 4 J1NA00920080
36 Bolt 8 J1BEB0803535 J1BEB1004526
37 Square Spacer 4 MS006010 MS006020
