1.3 Hook and Chain Parts
Figure
No.
Part Name
Parts
Per
Hoist
010L
1
Top Hook Assembly
1
2ASF010S5101
2
Hook Latch
1
2ASF010S1103
3
Suspender E (For Manual Trolley) –
White Epoxy Paint
1
36FG0109004
Suspender E (For Manual Trolley) –
Nickel Plated
37FG0109004
4
Connection Yoke P (For Push Trolley) –
White Epoxy Paint
1
2AFG005S9027
5
Connection Yoke G (For Geared Trolley) –
White Epoxy Paint
1
2AFG005S9029
6
Yoke Bolt
1
2AFG005S9032
7
Slotted Nut
1
J1NL00910100
8
Split Pin
1
J1PW06025018
9
Suspender T (For Motorized Trolley) –
White Epoxy Paint
1
2AFG010S9031
Suspender T (For Motorized Trolley) –
Nickel Plated
2AFG010S9831
10
Top Pin
2
WR2CS9121
11
Plate A
1
ER2CS9123
12
Socket Bolt
1
J1BEE0601414
13
Shaft Clip
1
ER2CS9186
14
Chain Guide A
1
ER2DS9331
15
Chain Guide B
1
ER2DS9332
16
Socket Bolt
4
J1BEE0802525
17
Spring Lock Washer
4
J1WS07420080
18
Machine Screw With Spring Washer
4
J1AP45001212
19
Guide Roller
1
ER2DS9333
20
Roller Pin
1
ER1CS9334
21
Limit Lever
1
ER2DS9337
22
Limit Lever Pin
1
ER2DS9338
23
Limit Lever Spring
1
WR2CS9357
24
Cushion Rubber – Standard
2
ER1DS9053
Cushion Rubber – Stainless Steel
2
27SF010S9117
25
Stopper Assembly – Standard
1
ER1DS1041
Stopper Assembly – Nickel Plated
2AFG010S1041
26
Bottom Hook Complete Assembly –
White Epoxy Paint
1
2AFG010S1011
Bottom Hook Complete Assembly –
Stainless Steel
2ASF010S5211
27
Hook Latch
1
2ASF010S1103
28
Plastic Chain Container Assembly
(Max. Lifting Height 20ft)
1
PBK2-D-FG
29
Plastic Chain Container
1
ER2DS1401
30
Plastic Container Spring Assembly
1
2AFG010S1416
31
Canvas Chain Container Assembly
(Max. Lifting Height 50ft)
1
BK2D2-FG
32
Canvas Chain Container
1
ER2DS5405
33
Socket Bolt
1
J1BEB0809028
34
Lever Nut
1
J1NU00920080
35
Socket Bolt
1
J1BEB0604508
36
Lever Nut
1
J1NU00920060
37
NP Load Chain
1
LCER2010NP-FG
37
ND Load Chain
1
LCER2010ND-FG
43
Washer
1
J1WB07420060
44
Spring Lock Washer
1
J1WS07420060
45
Stainless Steel Chain Container Assembly –
maximum 26 ft. lift
1
7042203
Stainless Steel Chain Container Assembly –
maximum 49 ft. lift
7042205
