1.3 Hook and Chain Parts
Figure
No.
Part Name
Parts
Per
Hoist
003L/LD
005L/LD
1
Top Hook Assembly
1
2ASF005S5101
2
Hook Latch
1
2ASF005S1103
3
Suspender E (For Push Trolley) –
White Epoxy Paint
1
36FG0059004
Suspender E (For Push Trolley) –
Nickel Plated
37FG0059004
Suspender E (For Geared Trolley) –
White Epoxy Paint
36FG0109004
Suspender E (For Geared Trolley) –
Nickel Plated
37FG0109004
5
Connection Yoke P (For Push Trolley) –
White Epoxy Paint
1
2AFG005S9027
6
Connection Yoke G (For Geared Trolley) –
White Epoxy Paint
1
2AFG005S9029
7
Yoke Bolt
1
2AFG005S9032
8
Slotted Nut
1
J1NL00910100
9
Split Pin
1
J1PW06025018
10
Suspender T (For Motorized Trolley) –
White Epoxy Paint
1
2AFG010S9031
Suspender T (For Motorized Trolley) –
Nickel Plated
2AFG010S9831
11
Top Pin
2
WR2CS9121
12
Plate A
1
ER2CS9123
13
Socket Bolt
1
J1BEE0601414
14
Shaft Clip
1
ER2CS9186
15
Chain Guide A
1
ER2CS9331
16
Chain Guide B
1
ER2CS9332
17
Socket Bolt
4
J1BEE0602525
18
Spring Lock Washer
4
J1WS07420060
19
Limit Lever
1
ER2CS9337
20
Limit Lever Pin
1
ER2CS9338
21
Limit Lever Spring
1
WR2CS9357
22
Cushion Rubber – Standard
2
ER1CS9053
Cushion Rubber – Stainless Steel
2
27SF005S9117
23
Stopper Assembly – Standard
1
ER1CS1041
Stopper Assembly – Nickel Plated
2AFG005S1041
24
Bottom Hook Complete Assembly –
White Epoxy Paint
1
2AFG005S1011
Bottom Hook Complete Assembly –
Stainless Steel
2ASF005S5211
25
Hook Latch
1
2ASF005S1103
26
Plastic Chain Container Assembly
(Max. Lifting Height 20ft)
1
PBK2-C-FG
27
Plastic Chain Container
1
ER2CS1401
28
Plastic Container Spring Assembly
1
2AFG005S1416
29
Canvas Chain Container Assembly
(Max. Lift Height 50ft)
1
BK2C2-FG
30
Canvas Chain Container
1
ER2CS5405
31
Socket Bolt
1
J1BEB0807528
32
Lever Nut
1
J1NU00920080
33
Socket Bolt
1
J1BEB0604508
34
Lever Nut
1
J1NU00920080
35
NP Load Chain
1
LCER2005NP-FG
35
ND Load Chain
1
LCER2005ND-FG
43
Washer
1
J1WB07420060
44
Spring Lock Washer
1
J1WS07420060
45
Stainless Steel Chain Container Assembly
– maximum 23 ft. lift
1
7042201
Stainless Steel Chain Container Assembly
– maximum 49 ft. lift
7042202
