15
9.1 ED1050 ADDITIONAL PARTS
Fig. No. Part Number Part Name
Qty Per
Hoist
5 E3DBX48S1470 Connection yoke complete set 1
6 E3DBX48S6460 Top hook assembly 1
7 CF071005 Hook Latch assembly 1
8 E3DBX48S9470 Connection yoke 1
9 ES006005L Top Pin, L 1
10 L3183008 Slotted nut 1
11 9009403 Split pin 1
15 E3DBX48S9580 Joint yoke 1
16 E3DBX48S9592 Protection pad 1
17 J1AG25003535 Truss head machine screw 1
18 9012510 Washer 1
19 9098503 U nut 1
20 E2D041125 Chain pin 1
21 E2D049125 Slotted nut 1
22 9009402 Split pin 1
23 E3DHX48S1480 Bottom hook complete set 1
24 E3DBX48S2480 Bottom yoke assembly 1
25 ER1BS9002 Hook latch assembly 1
26 E3DBX48S2485 Bottom yoke assembly 1
27 E3DBX48S9485 Bottom yoke 2
28 9093307 Bolt 2
29 9012709 Spring lock washer 2
30 9093420 Nut 2
31 E3DBX48S6489 Bottom shaft assembly 1
32 E3DBX48S6487 Idle sheave assembly 1
33 ES026003 Thrust collar A 1
34 ES027003 Hook stopper 2
35 ES022003 Thrust bearing 1
36 E3DBX48S9597 Name plate C 1
37 E3DBX48S9590 Chain spring 1
38 E3DBX489591 Washer 1
