- JOYSTICK AMPLIFIER CONNECTIONS -
The inputs to the Joystick Amplifier is designed to be attached to up to 16 potentiometers. Typical
value for the pots is 10 Kohm. To ease the job of wiring to the pots, a 50 wire ribbon cable is used for the
input. Starting from the number one wire position, the first wire goes to one side of the pot, the next goes
to the middle (wiper) pole of the pot, and the third wire goes to the third connection of the pot. This then
repeats for the other 15 pots. The pin out for the connector is as follows:
PIN #1 BROWN Negative Reference #16
PIN #2 RED Joystick Amplifier Input #16
PIN #3 ORANGE Positive Reference #16
PIN #4 YELLOW Negative Reference #15
PIN #5 GREEN Joystick Amplifier Input #15
PIN #6 BLUE Positive Reference #15
PIN #7 VIOLET Negative Reference #14
PIN #8 GRAY Joystick Amplifier Input #14
PIN #9 WHITE Positive Reference #14
PIN #10 BLACK Negative Reference #13
PIN #11 BROWN Joystick Amplifier Input #13
PIN #12 RED Positive Reference #13
PIN #13 ORANGE Negative Reference #12
PIN #14 YELLOW Joystick Amplifier Input #12
PIN #15 GREEN Positive Reference #12
PIN #16 BLUE Negative Reference #11
PIN #17 VIOLET Joystick Amplifier Input #11
PIN #18 GRAY Positive Reference #11
PIN #19 WHITE Negative Reference #10
PIN #20 BLACK Joystick Amplifier Input #10
PIN #21 BROWN Positive Reference #10
PIN #22 RED Negative Reference #9
PIN #23 ORANGE Joystick Amplifier Input #9
PIN #24 YELLOW Positive Reference #9
PIN #25 GREEN Negative Reference #8
PIN #26 BLUE Joystick Amplifier Input #8
PIN #27 VIOLET Positive Reference #8
PIN #28 GRAY Negative Reference #7
PIN #29 WHITE Joystick Amplifier Input #7
PIN #30 BLACK Positive Reference #7
PIN #31 BROWN Negative Reference #6
PIN #32 RED Joystick Amplifier Input #6
PIN #33 ORANGE Positive Reference #6
PIN #34 YELLOW Negative Reference #5
PIN #35 GREEN Joystick Amplifier Input #5
PIN #36 BLUE Positive Reference #5
PIN #37 VIOLET Negative Reference #4
PIN #38 GRAY Joystick Amplifier Input #4
PIN #39 WHITE Positive Reference #4
