for the servo motor. The other sets the length of the 'stroke' away from the retract position, and therefore
the extended position. The retract position is always set before you try to set the 'extend' position.

Some caution must be used when adjusting servo motors or mechanical movements which may be

damaged by being commanded to go to a position beyond that which they are designed to move. In
these cases it is sometimes best to adjust both the retract and stroke trimpots to a center position for the
movement and then adjust them slowly outward from there.

The 16 Channel Servo Motor Controller comes in a plastic case which can be mounted by simply

double face taping it where ever you need. If you need to mount it more solidly, then put screws
through the back of the case as needed. The front of the case can be removed for service and adjust-
ment after the box has been mounted.

The capabilities of the Servo Motor Controller outputs are as follows:

OUTPUT:

OPEN COLLECTOR SWITCH TO GROUND

PULLUP:

4.7K PULLUP TO + SERVO POWER SUPPLY

OUTPUT CURRENT:

16 ma MAXIMUM

OUTPUT/SERVO VOLTAGE:

5 VDC NOMINAL / 36 VDC MAXIMUM
