ST55GF
P2: 8-Pin Processor Power Connector
Connector housing: 8- Pin Molex : 39-01-2080 or Equivalent Contact: Molex 44476-1111 or Equivalent
4-Pin HDD / CD ROM Drive Power Connectors
Connector housing: 4- Pin AMP: 1-480424-0 or Equivalent Contact: Amp 61314-1 or Equivalent
Small 4-Pin : Floppy Disk Drive Power Connectors
Connector housing: 4- Pin AMP: 171822-4 or Equivalent
10. Physical Characteristics Size
10.1 Dimension : 150.0mm(W) x 85.0mm(H) x 200.0mm(D)
10.2 Weight: 4.75 Kg
Pin
1
2
3
4
5
6
7
8
Signal Color Size Pin Signal Color Size
COM Black 18 AWG
COM Black 18 AWG
COM Black 18 AWG
COM Black 18 AWG
18 AWG +12 VDC Yellow
18 AWG +12 VDC Yellow
18 AWG +12 VDC Yellow
18 AWG +12 VDC Yellow
Pin
1
2
3
4
Signal Color Size
18 AWG
Black 18 AWG
Black 18 AWG
Red 18 AWG
COM
COM
+5 VDC
+12 VDC Yellow
Pin
1
2
3
4
Signal Color Size
22 AWG
Black 22 AWG
Black 22 AWG
Red
22 AWG
COM
COM
+5 VDC
+12 VDC Yellow
