Product Basics
Camera
Remote Control
Battery Clip
To Camera
Power Jack
9V Battery
Connector
(battery included)
1
2
3
4
5
6
7
8
+
CHANNEL REMOTE
Channels
Number
Lock/
Unlock Key
Channel
Down
Circulator
Setup Key
Channel
Up
ADJU
ST FOCU
S
Antenna
Power Jack
Dip-Switch
Holes for Focus
Adjustment Tool
Adjustable lens
Bracket
Focus Adjustment
Tool
Camera Back
12
1
2
CH1 CH2 CH3 CH4
