SAMPI MP-070 Meter - Manual (Page 2)

Dimensions: flow meters with mechanical registration
Model Flow rate
Flange
size
Net weight Max working pressure
Dimensions
A C
MP070
Intermittent
(1):
3082 GPM
(700 m³/h)
Nominal (2):
2466 GPM
(560 m³/h)
10” ANSI
150
882 lbs
(400 kg)
19 bar @ -29°C to 38°C
in
mm
31.5
800
9.6
245
18 bar @ -29°C to 85°C
in
mm
31.5
800
9.6
245
14 bar @ -29°C to 180°C
in
mm
31.5
800
9.6
245
10” ANSI
300
1213 lbs
(550 kg)
49 bar @ -29°C to 38°C
in
mm
31.5
800
9.6
245
47 bar @ -29°C to 85°C
in
mm
31.5
800
9.6
245
44 bar @ -29°C to 180°C
in
mm
31.5
800
9.6
245
Dimensions
E Q1 Q2 L F G
in
mm
12.7
322
15.6
395
25.7
652
25.6
650
9.84
250
20.5
521
in
mm
12.7
322
15.6
395
25.7
652
25.6
650
9.84
250
20.5
521
in
mm
12.7
322
15.6
395
25.7
652
25.6
650
9.84
250
20.5
521
in
mm
12.7
322
15.9
404
25.7
652
26.4
670
9.84
250
20.5
521
in
mm
12.7
322
15.9
404
25.7
652
26.4
670
9.84
250
20.5
521
in
mm
12.7
322
15.9
404
25.7
652
26.4
670
9.84
250
20.5
521
Note (1): Maximum intermittent flow rate (batch use) means 8/24 hours of operation per day.
Note (2): Maximum nominal flow rate (continuous use) means 24/24 hours of operation per day.
