SAMPI LC Sound - Manual

The LC Sound is an ultrasonic air sensor, available
with 2”, 3”, 4” square flange. It continuously
monitors the presence of air/gas in a delivery, and
upon detection of gas the output relay is opened.
The typical application uses the output contact to
control valve, pump or can be connected to a
smart device. The technology guarantees accurate
deliveries with no pressure drop, both in terminal
and truck installations. The sensor uses an
ultrasonic transceiver to transmit a high frequency
pulse: the signal reaches the reflector placed on
the other side of the flange and then comes back
to the transceiver. The signal amplitude level is
proportional to the presence of liquid: if air is
detected, the output relay is opened.
LC Sound
Specifications Sheet
Features
 Fast response time (50 ms)
 Auto-calibration
 No periodic maintenance needed
 No moving parts
 Low weight
 Small dimensions give a neat to simple installation
 Negligible pressure drop resulting in quick and economical
deliveries
 Eliminates the need of an “Air-check” valve after the meter (in
the meter version with n° 2 LC Sounds)
 Can react to emulsified air in the delivery (foam detect)
 Works with petroleum based products
Certifications
 Electromagnetic compatibility EMC 89/336/CEE and successive laws
 Explosive atmospheres ATEX 94/9/CE
 Recommendations OIML (International Organization for Legal Metrology) R 117
