Specifications
MP-180 Meter
Liquid Controls MP Series Bi-Rotor Positive Displacement
(PD) Meters offer the ultimate in measurement accuracy for
custody transfer of petroleum and aviation fuels.
Superior performance features
Low pressure drop – the straight-through path and floating rotor
design creates a very low pressure drop at maximum flow.
Sustained accuracy – no metal-to-metal contact inside the
measuring chamber means minimal wear and deterioration in
accuracy over time, fewer recalibrations and a longer service life.
Wide viscosity range – LC meters can accurately meter
products up to 1000 cP (please consult factory for higher
viscosity).
Compact design – no upstream or downstream pipe lengths are
necessary.
Double case construction – the measuring unit is removable, as
a single subassembly, from the outer flanged.
Low piping vibration – the bi-rotor design produces very low
piping vibrations permitting to reach higher flowrates.
Accuracy/Performance
Repeatability
Mechanical registration: capable of 0.05% of reading over entire range
Electronic registration: capable of 0.03% of reading over entire range
Linearity
Over 5:1 range
Mech. registration: capable of ±0.125% or better from max nom. flow rate
Elect. registration: capable of ±0.10% or better from max. nom. flow rate
Over 10:1 range
Mech. registration: capable of ±0.22% or better from max. nom. flow rate
Elect. registration: capable of ± 0.10% or better from max. nom. flow rate
Over 40:1 range
Mech. registration: capable of ±0.5% or better from max. nom. flow rate
Elect. registration: capable of ±0.15% or better from max. nom. flow rate
Temperature range
-2.2° F to 356° F (-29° C to 180° C)
Note: with POD installed directly on the meter, temperature range is
reduced to: -2.2° F to 185°F (-29° C to 85 °C)
Industries served
LC MP-Series meters are
well-suited for use in
industries requiring precise
flow measurement and
reliable, extended service
life:
• Refined petroleum
products
• Crude oil
• LPG
• Power plant
• Petrochemicals
Construction
Class 1, 8 ,14
External housing:
Carbon steel ASTM A216
WCB
External cover:
Carbon steel ASTM A216
WCB
Housing:
Cast iron (1, 14)
316 stainless steel (8)
Bearing plate:
Cast iron (1, 14)
316 stainless steel (8)
Sleeve bearing:
Carbon/420 stainless steel
(1, 14)
Carbon/316 stainless steel
(8)
Rotors:
Cast iron (1, 14)
316 stainless steel (8)
Gear:
420 stainless steel (1, 14)
316 stainless steel (8)
Internal hardware:
Stainless steel
Seal material:
Teflon
Packing gland:
Stainless steel/teflon
