SAMPI TE550 Electronic Register (Truck Version) - Manual

The TE550 Electronic Register is the latest state of the art,
fully programmable electronic register capable to drive
any meter giving a pulse signal, either for direct ore
remote mounting, especially designed for both terminal
and truck.
TE550 is a freely programmable, flexible, powerful and
intelligent loading system, designed to match the
requirements of loading systems in petroleum, chemical
and petrochemical industry.
TE550 is designed to comply with international metrology
approvals, especially with the OIML R117 standards,
European ATEX Ex-d [ia]IIB T4 approval for hazardous
areas and Measuring Instruments Directive (MID).
TE550 includes all the flow measurements and controls
functions expected in the most advanced loading systems.
TE550 Electronic Register
(Truck Version)
Specifications Sheet
Other features
LKI specifications
Calculated accuracy Temperature accuracy
Ambient operating
temperature
Humidity
The gross standard volume
accuracy matches the OIML R117
class 05 instrument requirements
± 0.3°C from -25°C to 65°C
(± 0,5°F from -13°F to 149°F)
-25°C to 55°C
(-13°F to 131°F)
5% to 95% with
condensation
 TE550 is provided with a self-powered system so counting can be also carried
out without the truck battery power
 It can be carried out the tankers tracking from a terminal to see where, when
and how much product has been supplied
 Accurate flow measurement, including pulses verification
 Ten point calibration feature for near-perfect accuracy across entire flow
range with all kind of PD or gravity meter
 Temperature volume compensation
 Volume correction to API tables for the most of the petroleum products and
to Metric or US standards
 Total or partial control of each valve
 Electronic printer for delivery report and events print
 Memorization and report of all the main operations of the register
 Easy to install
