Programming
F232133 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
1a to 3b
This configuration eliminates the prewash step. Refer
to Figure 9.
Figure 9
1a to 3b to 5b
This configuration eliminates the prewash step and
shortens the final spin time from four minutes to two
minutes. Refer to Figure 10.
Figure 10
1a to 5a
This configuration shortens the prewash step from four
minutes to two minutes. Refer to Figure 11.
Figure 11
1a to 5a to 5b
This configuration shortens the prewash step from four
minutes to two minutes and shortens the final spin
time from four minutes to two minutes. Refer to
Figure 12.
Figure 12
1a to 5b
This configuration shortens the final spin time from
four minutes to two minutes. Refer to Figure 13.
Figure 13
6. The even-numbered side of the program timer
can be configured with jumpers to adjust the
rinse temperature or to change the water level for
the wash step. Refer to Figure 14.
Figure 14
Figure 15 and Figure 16 illustrate the different options
available.
1b 1 1a
3b 3 3a
5b 5 5a
1b 1 1a
3b 3 3a
5b 5 5a
1b 1 1a
3b 3 3a
5b 5 5a
1b 1 1a
3b 3 3a
5b 5 5a
1b 1 1a
3b 3 3a
5b 5 5a
0b 0 0a
2b 2 2a
4b 4 4a
6b 6 6a
8b 8 8a
10b 10 10a
12b 12 12a
14b 14 14a
16b 16 16a
18b 18 18a
20b 20 20a
