Ransburg, Aquablock 2 - parts identification – Ransburg AquaBlock2 A12148-XX User Manual
Page 43
AquaBlock 2 - Parts Identification
38
Figure 9b: AquaBlock 2 Assembly Parts Identification
SECTION A-A
32 INCHES REF.
** FLUID INLET 18 INCHES
** RIGHT CYLINDER TO TOP RIGHT PORT 12 1/2 INCHES
** TOP LEFT PORT TO TOP RIGHT PORT 29 INCHES
** BOTTOM LEFT AND RIGHT PORTS 17 INCHES EACH
** TOP LEFT AND RIGHT
PORTS 16 1/2 INCHES
LN-9902-00.3
Ransburg
