Ransburg, Aquablock 2 - maintenance – Ransburg AquaBlock2 A12148-XX User Manual
Page 30
1
LAQU0024-00
Center Section, Machined, Cylinder/Reservoir
1
2
LAQU0013-00
Plate, Machined, Cylinder Support
1
3
LSFA0017-00
SFHC Screw, 1/4-20 x 1/2" Lg.
4
4
LAQU0010-00
Piston, Machined
2
5
LAQU0012-02
Connecting Rod, Machined, Cylinder/Reservoir
1
6
LSFA0016-00
Jam Nut, 1.06-20 UN, Nylon
2
7
LAQU0011-00
Plate, Machined, Piston Seal
2
8
LSOR0007-03
O-Ring, 60 Duro
2
9
LAQU0027-00
Seal, O-Ring Loaded, Cylinder/Reservoir Piston
2
10
77725-02
Cylinder/Reservoir Assembly, Paint
2
Item #
LKIT0018-06 200CC CERAMIC CYLINDER ASSEMBLY -
PARTS LIST (Figure 6)
Part #
Description
Qty
AquaBlock 2 - Maintenance
25
LN-9902-00.3
Ransburg
