AquaBlock 2 - Introduction
6
† Most power supplies manufactured by
Ransburg can be used with the AquaBlock
2 System. However, in existing installa-
tions where older models are in use, the
high voltage system should be pre-tested
using the recommended test procedure to
determine if a newer, more suitable model
should be installed for best performance.
Where competitive models are in use, the
same test procedure should be applied.
Our service representatives can assist
you in conducting this test.
NOTE
Air
Air Supply: 90 psi +/- 5 psi
(6.2 bar +/- 0.3 bar)
10 SCFM Maximum
(Air required for cylinder
sensing curcuit) (283 slpm)
Air Filtration: 25-50 Micron
Paint Supply
Pressure: 100 psi Maximum (6.9 bar)
20 psi Minimum (1.4 bar)
Volume: See Maximum Pressure
(Depending on viscosity)
Temperature: 120°F Maximum (49°C)
Dimensions: 30" Wide X 36" High X 13"
Deep
(76.2 cm Wide X 91.4 cm High
X 33.0 cm Deep)
Weight: 110 lbs. (Approx.) (50 Kg)
High Voltage: 90kV Maximum
SPECIFICATIONS
Filtration is required for paint, water, and/or solvent
supplies connected to the system.
† The AquaBlock 2 is not intended for use
with emulsion type materials. If concerned,
test material thoroughly.
NOTE
Physical
Electrical
Mechanical
† DO NOT USE TAP WATER FOR
FLUSHING OR CLEANING. Deionized
water is the acceptable material.
C A U T I O N
!
† The AquaBlock 2 is intended for use
with non-flammable coating materials. The
flash point of all coating materials, cleaning
solvents, etc., must be greater than 100°F.
W A R N I N G
!
LN-9902-00.3
