AquaBlock 2 - Installation

11

INSTALLATION

†

This manual

MUST be read and thor-

oughly understood by

ALL personnel who

operate, clean, or maintain this equipment.

Special care should be taken to ensure

that the

WARNINGS and requirements for

operating and servicing are safely followed.

W A R N I N G

†

This connection uses a metal fitting

which is grounded through the current me-

ter. No other metal fittings should be used

to replace plastic connections located on or

in this cabinet.

C A U T I O N

!

!

AQUABLOCK 2 LOCATION

The AquaBlock 2 cabinet is installed between the

grounded coating supply and the electrostatic

spray applicator(s). This system provides a “volt-

age block” to prevent high voltage from following

the conductive path through the water based paint

line connected from the spray applicator(s), which

are at high voltage, and the grounded paint supply.

The unit should be installed near the spray

equipment to minimize the length of fluid line to

be flushed and also minimize the amount of fluid

hose that will be charged at high voltage potential.

MOUNTING

1. Mount the unit onto an appropriate structure

in or near the spray booth using four bolts (7/16"

minimum diameter).

2. Ground the unit by attaching the grounding

cable provided to a suitable earth ground.

PNEUMATIC

CONNECTIONS

1. From a filtered and regulated air supply, con-

nect 3/8" or 10mm OD tubing to the fitting labeled

†

All AquaBlock 2 installations must com-

ply with appropriate local, state, and national

codes governing ventilation, fire protection,

operation, maintenance, and housekeeping.

†

Refer to OSHA, NFPA-30, NFPA-33,

and customer's insurance requirements.

W A R N I N G

!

†

The air supply pressure to the Aqua-

Block 2 system must be between 85 and

95 psi (90 psi nominal).

NOTE

“AIR SUPPLY” on the top of the cabinet.

2. Connect 1/4" or 6mm OD tubing from the fitting

labeled

“HIGH VOLTAGE INTERLOCK” to the

appropriate pressure switch connection on the

power supply. When the cabinet door is open,

the high voltage power supply is de-energized.

PAINT SUPPLY

1. Connect 3/8" or 8mm OD tubing from the

water based coating supply to the fitting labeled

“FLUID INLET” on the top of the cabinet.

LN-9902-00.3
