INTRODUCTION
DESCRIPTION
Color Select System
The CCV-6100 Color Select System is a manu-
ally controlled pneumatic color change system.
The system consists of one or two color change
boxes, a Color Change Valve Stack, and 1/4 inch
OD poly tubing. The system allows for up to and
including (15) different colors. Color changes are
made using CCV-403-SS color change valves.
Valve
The CCV-403-SS is a pneumatically operated fluid
valve designed for use in paint spray application
systems. The valve can be used in a variety of
other applications. The valve can be used sepa-
rately for on/off control of paint to a spray atom-
izer; or, as part of a multi-color manifold assembly
where colors can be quickly flushed and changed
when a color change is desired.
All parts that come in contact with the fluid mate-
rial are made of either stainless steel or PTFE
that is impervious to most solvents. All other
parts of the valve are made of brass, stainless
steel, nickel-plated brass or hard coated (anod-
ized) aluminum. The valve is constructed with a
smooth, unobstructed fluid path that allows for
faster flush cleaning, and also less pressure re-
striction. The valve body has two fluid inlet ports
that allow fluid to circulate through the valve on
a continuous basis. A plug is provided when this
feature is not to be used. The double inlet ports
also allow two valves to be used as a fluid on/off
control and dump system.
Main Box
The main box consists of two six-position pneu-
matic switches. The top switch switches between
off, air solvent and color. The color select posi-
tion activates the bottom color switch and the
secondary box (if more than five colors are to be
used). The bottom switch is used to select colors
1 through 5. All internal plumbing is 5/32 nylon
tubing. The external bulkhead fittings are for 1/4
inch O.D. tubing, including the supply air fitting.
When High Voltage is on, both Solvent Flush
and Air Push are locked out so they cannot be
triggered.
Secondary Box
The secondary box also consists of two six posi-
tion pneumatic switches. The top switch selects
color 6 through 10, the bottom 11 through 15. All
internal and external tubing connections are the
same sizes as the main box.
>
When using the secondary box, all color
select switches not in use must be set in
the OFF position.
NOTE
