2. With stem fully inserted into assembly, tighten
the clamping nut onto the stem and torque to
specifications shown on the “CCV-403-SS Parts
List” in the “Introduction” section. Do not rotate
the stem during assembly.
3. Apply a thin film of lubricant (light grease type)
to the valve cap bore and cup as shown on page
1. Tighten the valve cap to the torque specification
on the “CCV-403-SS Parts List” in the “Introduc-
tion” section.
>
Make sure all seating surfaces of the
stem, poppet seat, needle seal, and cup
are clean and free of nicks and scratches
to prevent leakage.
NOTE
Color Select Boxes
Air Switch Removal
Disconnect all air lines to the air switch.
While holding the front of the air switch, loosen
nut on rear of air switch and remove nut.
Remove air switch.
Air Switch Reassembly
Insert air switch into front panel of the Color Se-
lect box.
Align air switch so selector is in the “OFF” position.
Install nut on rear of air switch, making sure to
hold the front of the air switch firmly in place while
tightening the nut.
Air Pilot Valve Removal
Disconnect all air lines to the pilot valve.
Loosen two (2) screws on top of pilot valve. Do
not remove screws entirely.
Remove pilot valve.
Air Pilot Valve Reassembly
Align pilot valve alignment pin with base, and
place pilot valve on base.
Tighten two (2) screws on top of pilot valve.
19
