OPERATION
The flow of the coating material is controlled by
selecting the proper color number on the Color
Select Boxes. If two Color Select Boxes are used,
all Color Select Switches not in use must be set to
the OFF position. After the proper color number
is selected, the coating material is activated by
selecting the “Color Select” position.
Installation and Operation
Overview
The coating material is supplied from the users
pressurized system that may be a pressure tank,
paint circulating system or other suitable pressure
paint supply system. 3/8-inch OD fluid tubing is
connected between the users paint supply and
the CCV.
An air signal supplied to the CCV activates the
paint being delivered to the applicator. The air
signal is controlled by the Color Select Boxes.
1/4-inch OD air tubing is used to connect the
control air between the Color Select Boxes and
the CCV.
NOTES
>
To select a new “Color”, the main switch
must be moved from the “COLOR SELECT”
to the ‘OFF” position.
To flush the coating material from the
coating system, select the “SOL.” position,
which will activate the solvent. The “AIR”
position can be used to blow the coating
material or the solvent out of the coating
system.
NOTE
