INSTALLATION
Mounting
The Color Select Box and the Color Change Valve
stack have mounting brackets for easy mounting.
The Color Select Boxes may be mounted using
the pattern supplied in this manual (See Figure
10). Mounting hardware can be any type 1/4-
inch bolt with washers. A minimum of six inches
should be left between the air outlets on the box
and the Color Change Stack, to allow room for
the air tubing to be run later.
Air Tubing Connections
For the proper connection locations on the Color
Select Box, refer to Figure 2. The main supply air
must be dried and filtered. Using Figure 2, and
the “Installation Diagram,” Figure 9, the air tubing
can be run to the color Change Stack. The high
voltage signal air, “HV6,” may be used only if a
pneumatic control panel is being used. In this
case, HV6 is connected directly to HV6 on the
pneumatic control panel.
Coating Material Connections
Number the coating materials to correspond to the
numbers of the Color Select System. 3/8-inch OD
tubing is to be used to connect the Color Change
Valves to the coating material.
Connect the tubing from material (#1) to CCV (#1),
tubing from material (#2) to CCV (#2), and so on,
matching materials with the proper CCV.
>
The coating material must be pressur-
ized for the Color Select System to function
properly.
NOTE
>
The solvent must be pressurized for the
Color Select System to function properly.
NOTE
Solvent Connection
Installation of the Color Select System is made
simple by its ability to be placed in a Class I,
Division I environment. The color change valves
can be mounted as close to the paint or the ap-
plicator as is desired. The color select box can
be mounted right on the wall of the spray booth,
allowing for fast color changes, since the operator
does not have to leave the booth.
The solvent is connected in the same way as the
Coating Material, using 3/8-inch OD tubing.
