RMA-303 Dual Purge Direct Charge - Parts
91 LN-9267-11.3
RMA-303 DUAL PURGE DIRECT CHARGE ASSEMBLY - PARTS LIST
Item # Part # Description Qty
30 75921-02 Fiber Optic Cable Assembly 1
31 79010-00
Cascade Assembly, HP 404 (Straight Con-
nector)
1
32 Table D, Item D Shaping Air Kit 1
33 Table A, Item A Bell Cup (See Note 7) 1
34 A12290-01 Cup Wash Tube Assembly (Front) 1
35 A12290-02 Cup Wash Tube Assembly (Rear) 1
36 Table D, Item E Tool Kit 1
37 77141-23 Literature Kit (Not Shown) 1
Note 1 Tighten screws to a final torque of 15-20 lbs•in (1.69-2.26 Nm)
Note 2 Tighten air bolts to a final torque of 15 lbs•in (1.69 Nm)
Note 3 Tighten support rods to a final torque of 10-15 lbs•in(1.13-1.69 Nm)
Note 4 Torque fluid tube into atomizer body using A11229-00 tool to 65-76 lbs•in (7.34-8.47 Nm)
Note 5 Torque fluid tip using A11229-00 tool to 25-30 lbs•in (2.83-3.39 Nm)
Note 6 Lubricate all O-rings with Amojell (sparingly) to aid in installation
Note 7 Torque bell cup assembly to a final torque reading of 50-70 lbs•in (5.64-7.9 Nm)
