RMA-303 Dual Purge Direct Charge - Parts
LN-9267-11.3
90
RMA-303 Assembly
RMA-303 DUAL PURGE DIRECT CHARGE ASSEMBLY - PARTS LIST
DESCRIPTION
PART NUMBER
QTY
ITEM
ROD, SUPPORT (RMA-303 DUAL PURGE)
A11717-00
5
1
ASSY.' KNUCKLE RMA-303
A11230-00
1
2
O-RING, SOLVENT PROOF
79001-14
5
3
O-RING, SOLVENT PROOF
79001-07
13
4
FITTING, FLUID
78449-00
2
5
3/16 ODT X 1/4 NPT
76703-00
1
6
FERRULE, FRONT 1/4"
EMF-203-04
2
7
FERRULE, BACK 1/4"
EMF-202-04
2
8
O-RING
7554-05
1
9
VALVE MANIFOLD ASSEMBLY
A12289-00
1
10
REAR PLATE ASSEMBLY
A12288-00
1
11
O-RING, SOLVENT PROOF
79001-40
1
12
SCREW 1/4-20 STAINLESS STEEL
7683-16c
3
13
BOLT, AIR
77508-00
5
14
BREAK AWAY RING ASSEMBLY
A12287-00
1
15
SCREW, BREAKAWAY
77524-00
5
16
ASS'Y, FIBER OPTIC TRANSMITTER
75911-00
1
17
NUT, FIBER OPTIC TENSIONING
78278-00
1
18
0-RING, SOLVENT PROOF
79001-22
1
19
O-RING, SOLVENT PROOF
79001-42
1
20
O-RING, SOLVENT PROOF
79001-41
1
21
RETAINER, FLUID TUBE
A11226-00
1
22
FLUID TUBE ASSEMBLY
A11245-00
1
23
O-RING, SOLVENT PROOF
79001-44
1
24
FLUID TIP
TABLE "B" ITEM "B"
1
25
SPINDLE ASSEMBLY
TABLE "E" ITEM "E"
1
26
SHROUD, RMA-303
A11726-00
1
27
RING, QUICK DISCONNECT
A11201-00
1
28
COIL, FLUID
TABLE "C" ITEM "C"
1
29
FIBRE OPTIC CABLE ASSEMBLY
75921-02
1
30
CASCADE ASS'Y., HP 404 (STRAIGHT CONNECTOR)
79010-00
1
31
SHAPING AIR KIT
TABLE "D" ITEM "D"
1
32
BELL CUP
TABLE "A" ITEM "A"
1
33
CUP WASH TUBE ASSEMBLY (FRONT)
A12290-03
1
34
CUP WASH TUBE ASSEMBLY (REAR)
A12290-02
1
35
TOOL KIT
TABLE "D" ITEM "E"
1
36
LITERATURE KIT (NOT SHOWN)
77141-22
1
37
NOTE #2 longest fitting end installed into Knuckle (air Manifold) Assembly.
NOTE #1 Customer must verify spindle part number located on outer housing, see page 13.
SEE NOTE #1
SEE NOTE #2
