1.3 HP SERIES SPECIFICATIONS
HP… HP100A-3KW-HE HP100A-4KW-HE
Aperture Diameter 100 mm
Spectral Range 0.19 - 20 µm
Power Noise Level ± 3 W
Typical Rise Time
(0 – 95 %)
7 s
Sensitivity 0.5 mV/W 0.4 mV/W
Calibration Uncertainty ± 5 % @ 1.064 µm
Linearity
with Power
± 1.5 % ± 1.5 %
Repeatability
(Precision)
± 2%
Min. Average Power
(continuous)
100 W
7
100 W
7
Max. Average Power
(continuous)
3 000 W 4 000 W
Max. Average Power
(2 min.)
4 000 W 4500 W
Max. Average Power
Density
12
10 kW/cm² (0.5 kW)
6 kW/cm² (1 kW)
4 kW/cm² (2 kW)
3 kW/cm² (3 kW)
10 kW/cm² (0.5 kW)
8 kW/cm² (1 kW)
6 kW/cm² (2 kW)
4 kW/cm² (4 kW)
Dimension
(mm)
127 (H) x 127 (W) x 74 (D)
Weight
(head only)
1.8 kg
Cooling Water
Required cooling flow
4 – 6 LPM
< ± 1 LPM/min
3
Temp of cooling water
15 - 25 °C
< ± 3 °C/min
3
Pressure Drop < 6 psi < 6 psi
Recommended load
Impedance
> 100 kΩ
Output Impedance < 675 Ω
Linearity
vs beam dimension
± 1.0 %
Linearity
vs beam position
± 1.5 % 1
PCB electrical supply
USB or
Gentec-EO monitors
Maximum current
consumption
30 mA
Max output signal 2.0 V
1 For a beam size of 10% of the aperture area, moved across 80% of the aperture area.
