General Tools and Instruments MM1E v.1 - Manual (Page 8)

4. Conductive or metallic objects will always light the lowest
LED on the bar graph, regardless of the selected scale.
5. Measurements of wood are skewed by two variables:
ambient humidity and the density of the wood species. The
best way to compensate for the effect of these variables is
to develop your own moisture level curves, based on your
experience working with different species of wood on a
day-to-day basis.
6. The MM1E has no auto power off function. To avoid
discharging the battery, manually power off the meter after
each measurement session by sliding the Power/Scale
switch on the back to the OFF position.
SPECIFICATIONS
Measurement Range 7 to 35% WME (Wood Moisture
Equivalent) over two scales: 7% to
15% (Low) and 16% to 35% (High)
Measurement Accuracy ±1 LED (~1%)
Pin Length 3/8 in. (10mm)
Calibration Check Point 21% ±1%
Low Battery Alarm Level <7.5V
Operating Temperature 32° to 140°F (0° to 60°C)
@<80% R.H.
Storage Temperature 23° to 140°F (-5° to 60°C)
Current Consumption <15mADC
Dimensions 6.5 x 2.7 x 1 in. (164 x 69 x 26mm)
Weight 3.2 oz. (91g)
Power Source “9V” battery (included)
8
