General Tools and Instruments DLM105HA - Manual (Page 4)

Measurement LUX 0 - 50,000 LUX, 3 ranges.
& ranges Foot-candle 0 -5,000 Ft-cd, 3 ranges.
Relativity 0 to 1999 %.
(Relative to the range
selected and the measured
value)
Sensor The exclusive photo diode & color
correction filter, spectrum designed to meet
C. I. E.
Memory Records Maximum, Minimum and Average
Recall readings with RECALL facilities.
Sample Time Approx. 0.4 sec.
Zero Adj.
By push button.
Power off Manual off by push button, or Auto shut off
after 10 minutes.
Data Output RS 232 PC serial interface.
Over Load "- - - -"
Indication
Operating 0
蚓
to 50 蚓(32 蚌 to 122 蚌).
Temperature
Operating
Max. 80% RH.
Humidity
Power Supply 006P DC 9V battery(heavy duty)
or equivalent.
Power Current Approx. DC 5.3 mA.
Weight 335 g/0.77 LB (included batteries)
Size Main instrument:
180 x 72 x 32 mm(7.1 x 2.8 x1.3 inch).
Sensor probe:
85x55x12 mm(3.2x2.2x0.5 inch).
Accessories Instruction manual.
Sensor with protective cover.
2
