13
Settable parameters Date, time, auto power off, beep sound, sampling time,
decimal point or comma decimal division, temperature
unit, air speed unit, light level unit, optional thermocou-
ple type (K or J)
Storable/recallable readings Maximum, minimum
SD card capacity 1 GB to 16 GB
Operating temperature 32° to 122ºF (0° to 50ºC)
Operating relative humidity 0 to 85%
Power source 6 Alkaline “AA” batteries or optional 9-VDC AC adapter
Power consumption 3.5 mADC (normal operation, with backlight off and
SD card not saving data); 28 mADC with backlight on
and card saving data; 40 mADC with backlight on and
card saving data
Dimensions of meter 5.31 x 2.36 x 1.30 in. (135 x 60 x 33mm)
Weight of meter 1.13 lb. (515g) Dimensions of probe
4.13 x 1.81 x 1.14 in. (105 x 46 x 29mm)
MAINTENANCE & TROUBLESHOOTING TIPS
Keep the multi-function probe clean. Store it in the carrying case when you are not
using the meter.
When the icon appears in the left corner of the display, it’s time to replace the
six “AA” batteries that power the instrument (although measure ments will remain
valid for several hours after the low-battery indicator first appears). Replacing the
batteries requires removing the two screws that hold the battery compartment cover
in place, as explained earlier. After inserting fresh batteries in the correct orientation,
tighten the screws to secure the cover.
If the meter “freezes” (like a computer) and buttons become unresponsive,
try resetting the instrument by pushing the RESET button on its right side
(callout 1-11 of Fig. 1) with the end of a paper clip.
Remove the batteries when storing the meter for an extended period of time.
Do not drop or disassemble the meter or immerse it in water.
