GENERAL PUMP
A member of the Interpump Group
SM SERIES
Page 23
REPAIR KITS
KIT NUMBER
F2190 (SM14)
Plunger
Packing Kit
F2191 (SM16)
Plunger
Packing Kit
F2192 (SM18)
Plunger
Packing Kit
F2198 (SM20)
Plunger
Packing Kit
F2199 (SM22)
Plunger
Packing Kit
F2200 (SM240)
Plunger
Packing Kit
Positions
Included
8, 16, 17, 18,
19, 23, 25, 27
8, 16, 17, 18,
19, 23, 25, 27
8, 16, 17, 18,
19, 23, 25, 27
8, 16, 17, 18, 19,
23, 25, 27
8, 16, 17, 18,
19, 23, 25, 27
8, 16, 17, 18,
19, 23, 25, 27
KIT NUMBER
F2193
(SM14, SM16, SM18)
Valve Seals Kit
F2085
(SM20, SM22, SM24)
Valve Seals Kit
Positions
Included
6, 9
6, 9
KIT NUMBER
F2195 (SM14)
Complete
Seals Kit
F2196 (SM16)
Complete
Seals Kit
F2197 (SM18)
Complete
Seals Kit
F2201 (SM20)
Complete
Seals Kit
F2202 (SM22)
Complete
Seals Kit
F2203 (SM24)
Complete
Seals Kit
Positions
Included
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
6, 8, 9, 16, 17,
18, 19, 23, 25,
27, 34, 36, 54,
63, 73, 76
KIT NUMBER
F2150 (All SM models)
Connecting Rod
Bushing Kit
Standard
F2151 (All SM models)
Connecting Rod
Bushing Kit,
+0.25
F2153 (All SM models)
Connecting Rod
Bushing Kit,
+0.50
Positions
Included
45, 46
KIT NUMBER
F2194
(SM14, SM16, SM20)
Inlet & Outlet
Valves Kit
F2111
(SM20, SM22, SM24)
Inlet & Outlet
Valves Kit
Positions
Included
3, 4, 5, 6, 7,
9, 10, 11
3, 4, 5, 6, 7,
9, 10, 11
Ref 300893 Rev.A
06-12
KIT NUMBER
F2152 (All SM models)
Mounting Feet
Set
Positions
Included
41, 51
