Finish Thompson PFM/PFP/PFV Vapor Seal and Bearing Replacement - Manual

P P F F M M / / P P F F P P / / P P F F V V V V a a p p o o r r S S e e a a l l a a n n d d B B e e a a r r i i n n g g R R e e p p l l a a c c e e m m e e n n t t I I n n s s t t r r u u c c t t i i o o n n s s
D D i i s s a a s s s s e e m m b b l l i i n n g g t t h h e e p p u u m m p p
Remove the impeller housing cover by
turning it clockwise.
Spin the impeller until the hole in the bottom of
shaft can be seen through the square slot in the
impeller housing.
Insert a 3/32” pin into the hole in the shaft.
Holding the pin, remove the impeller from the shaft
by turning counterclockwise.
Once the impeller is removed, the bottom portion of
the shaft will be exposed.
