Model: M3V
Part No: 106655
Serial No.: 12345-A09
Output: 4/5 HP, 115 VAC, 50/60 Hz
Enclosure: 3 (WP) Splashproof
LR157411 Thermally Protected
Date of Manufacture: 3/31/2009
OPERATION
The MV Series motors incorporate an ON/OFF switch as well as a Variable Speed Control. When operating the MV Se-
ries for the first time it is recommended to turn down the speed control (Counter Clockwise) to the lowest setting. Make
sure the discharge hose is properly secured. Turn on the motor with the ON/OFF switch & adjust the speed control to the
desired flow rate. Both of these operations can be done with the same hand being used to support the pump utilizing the
thumb. Keep in mind that flow rates will vary depending upon fluid viscosity & specific gravity. It may be necessary to
operate the pump at a lower speed for high viscosity fluids. Contact factory for troubleshooting tips.
MOTOR IDENTIFICATION
(M3V Sample Label)
Motor Specifications
Model M3V M5V M5V-US
Part Number 106655 106658 106657
Nominal Voltage 115v 230v 230v
Input Power HP / Watts .8 / 650 .8 / 650 .8 / 650
Hertz 50 / 60
RPM’s (Variable Speed) 3,500-10,000
Enclosure 3(WP) Splash-Proof IP24 Splash-Proof
Certificates or Approvals
Max Viscosity cps / Density 500 / 1.8
Duty Cycle Continuous *
Applicable Pump Models PF / TB / TBP
5
*Contact Factory for brush life information.
