ITEM QTY DESCRIPTION PART NUMBER
1 1
COUPLING INSERT
J100014
2 1
COUPLING HALF
J100012
3* 1
BEARING ASSEMBLY
W/ ROLL PIN
A101110
4* 1
SEAL ASSEMBLY
PTFE
A103186
5 1
PUMP HEAD
PURE PVDF
M102222
6 1
INTAKE TUBE ASSEMBLY
27” PURE POLYPROPYLENE
M102221-1
40” PURE POLYPROPYLENE M102221-2
48” PURE POLYPROPYLENE M102221-3
7 1
IMPELLER ASSEMBLY
PTFE WITH ALLOY 625 PIN
A103190
8 1
SPACER SET
27” PURE POLYPROPYLENE
A103189-1
40” PURE POLYPROPYLENE A103189-2
48” PURE POLYPROPYLENE A103189-3
9 2
CENTER BEARING
PTFE
M100039-1
10 1
SHAFT
27” ALLOY 625
M102219-1
40” ALLOY 625 M102219-2
48” ALLOY 625 M102219-3
11 1
COMPRESSOR
PTFE WITH ALLOY 625 PIN
A103191
12 1
DISCHARGE O-RING
FKM
J100991
13 1
SPOUT
1” BARBED PURE PVDF
106753
14 1
DISCHARGE NUT
PURE PVDF
M101610-2
*Recommended Spare Parts
SPARE PARTS LIST
Service 1-800-888-3743
P/N 108100 REV. 3, 2/10/2014
