Page 11
ITEM
QTY
DESCRIPTION
PART NUMBER
1
1
COUPLING INSERT
J100014
2
1
COUPLING HALF
J100013
3*
1
BEARING ASSEMBLY
W/ ROLL PIN
A101672
4*
1
SEAL ASSEMBLY
PTFE (TTS)
A100284
5
1
LOCK WASHER
#8 BRASS (TTS)
J100823
6
1
SCREW
#8-32 X 1/4 BRASS PAN HEAD M/S
J100822
7
1
INTAKE TUBE ASSEMBLY
27” 316 STAINLESS STEEL (TTS)
A100927-1
40” 316 STAINLESS STEEL (TTS)
A100927-4
48” 316 STAINLESS STEEL (TTS)
A100927-3
27” CPVC (TTC)
A100926-1
40” CPVC (TTC)
A100926-4
48” CPVC (TTC)
A100926-3
8
1
IMPELLER ASSEMBLY
PTFE WITH STAINLESS STEEL PIN (TTS)
A100030
PTFE WITH ALLOY 625 PIN (TTC)
A100039
9*
4
COMPRESSOR
PTFE WITH STAINLESS STEEL PIN (TTS)
A100044
PTFE WITH ALLOY 625 PIN (TTC)
A100325
10
2
SPACER SET
FEP (TTS/TTC-40)
A100043-1
FEP (TTS/TTC-48)
A100043-2
11
1
SHAFT
27” 316 STAINLESS STEEL (TTS)
M100972-1
40” 316 STAINLESS STEEL (TTS)
M100972-7
48” 316 STAINLESS STEEL (TTS)
M100972-3
27” ALLOY 625 (TTC)
M100972-4
40” ALLOY 625 (TTC)
M100972-8
48” ALLOY 625 (TTC)
M100972-6
12*
1
CENTER BEARING
PTFE
M100039
13*
1
BOTTOM BEARING
PTFE
M100047
TTS/TTC SPARE PARTS LIST
9
*Recommended Spare Parts
