Finish Thompson AV 6 & 8 Series - Manual (Page 4)

4
Item Description
Part Numbers
AV6 AV6H AV8 AV8H
1
Motor Adapter
NEMA 182/184TC M101938-1 M101938-1 M101938-1 M101938-1
NEMA 213/215TC M101938-2 M101938-2 M101938-2 M101938-2
2
Motor Mount
M101940 M101940 M101940 M101940
3
Coupling Guard
304 stainless steel M101974 M101974 M101974 M101974
4
Flat Washer
1/2" stainless steel - 182/184TC, 213/215TC J101360 J101360 J101360 J101360
3/8" stainless steel - 56C, 143/145TC J100128 J100128 J100128 J100128
5
Lock Washer
1/2" stainless steel - 182/184TC, 213/215TC J101023 J101023 J101023 J101023
3/8" stainless steel - 56C, 143/145TC J100115 J100115 J100115 J100115
6
Hex Head Bolt
1/2-13 x 2-1/4” stainless steel J103208 J103208 J103208 J103208
7
Machine Screw
10-32 x 1/2" J100932 J100932 J100932 J100932
8
Flat Washer
Plated - #10 J101310 J101310 J101310 J101310
9
Coupling L-100
5/8" - 56C frame A102512 A102512 A102512 A102512
7/8" - 143/145TC frame A102513 A102513 A102513 A102513
1-1/8" - 182/184TC frame A102514 A102514 A102514 A102514
1-3/8" - 213/215TC frame A102515 A102515 A102515 A102515
9A
Coupling Insert
Fits all motor frames J103241 J103241 J103241 J103241
10
Top Bearing
J103116 J103116 J103116 J103116
11
Lip Seal
J103246 J103246 J103246 J103246
12
Lower Bearing Mount
M101939 M101939 M101939 M101939
13
Hex Head Bolt
Stainless steel - 3/8-16 x 1-1/4” J103118 J103118 J103118 J103118
14
Lock Washer
3/8" stainless steel J100115 J100115 J100115 J100115
15
Hex Head Cap Screw
3/8" - 16 x 1-1/2" stainless steel J103207 J103207 J103207 J103207
16
Flat Washer
3/8" stainless steel J100128 J100128 J100128 J100128
17
Mounting Plate
304 stainless steel J103121 J103121 J103121 J103121
18
Flat Washer
1/2" stainless steel J101360 J101360 J101360 J101360
19
Hex Head Bolt
1/2" - 13 x 1" stainless steel J101359 J101359 J101359 J101359
20
Lock Washer
1/2” stainless steel J101023 J101023 J101023 J101023
21
Hex Head Bolt
1/2-13 x 1-1/2” stainless steel J101858 J101858 J101858 J101858
1/2-13 x 2-1/4" stainless steel N/A N/A J103208 J103208
AV SPARE PARTS LIST
