Finish Thompson KC11 Series - Self Priming Option - Manual (Page 2)

Pump Material
Item Qty Description Polypropylene CF PVDF
1 1 MagPrime Chamber Assembly A101556
2 5 SS Hex Head Cap Screw J102279
3 5 SS Flat Washer J100113
4 4 Phillips Head Screw J101020
5 1 KC11 Impeller Housing A101014-1 A101014-2
6 1 Impeller Hub w/carbon bushing -3” A101931 A101939
Impeller Hub w/PTFE bushing - 3” A101935 A101943
Impeller Hub w/ceramic bushing - 3” A103109 A103113
Impeller Hub w/carbon bushing - 3.5” A101930 A101938
Impeller Hub w/PTFE bushing - 3.5” A101934 A101942
Impeller Hub w/ceramic bushing - 3.5” A103108 A103112
Impeller Hub w/carbon bushing - 4.0” A101929 A101937
Impeller Hub w/PTFE bushing - 4.0” A101933 A101941
Impeller Hub w/ceramic bushing - 4.0” A103107 A103111
Impeller Hub w/carbon bushing - 4.5” A101928 A101936
Impeller Hub w/PTFE bushing - 4.5” A101932 A101940
Impeller Hub w/ceramic bushing - 4.5” A103106 A103110
6A 1 PTFE thrust ring J101606
6B 1 Carbon bushing only J100977
PTFE bushing only J100977-1
Ceramic bushing only J100977-2
7 1 Viton o-ring J102774
1 EPDM o-ring J102775
8 1 KC11 Barrier Assembly A101008-1 A101008-2
9 1 Drive Magnet Assembly
- fits 56C motors A101019-1
- fits 145TC motors A101019-2
- fits 80 frame motors A101019-3
- fits 90 frame motors A101019-4
10 4 SS Socket Head Cap Screws
- U.S. J101000
- Metric (80 frame) J101080
- Metric (90 frame) J101081
11 4 SS Lock Washers
- Metric (80 frame) J100672
- Metric (90 frame) J102282
12 4 SS Hex Nut J100321
13 1 Motor Adapter
- U.S. M101629-1
- Metric (80 frame) M101629-2
- Metric (90 frame) M101629-3
14 1 1/2” Pipe Plug J102183
14A 1 O-ring J102280
15 1 1” Pipe Plug J102187
15A 1 O-ring J102281
2
