16
Hardware- All DB22 Models
Item Qty Description Stainless Steel Titanium
11 10
Housing Bolt
106501 106502
12 10
Housing Lock Washer
106503 106504
13 10
Housing Flat Washer
106505 106506
14 4
Motor Adapter Bolt
All frame sizes except 213/215TC 106495 106498
213/215TC 106511 106512
15 4
Motor Adapter Lock Washer
J101023 105762
16 4
Motor Adapter Flat Washer
106497 106500
17 1
Drive Bolt (IEC Only)
90 frame 105770 105771
100/112 frame 105774 105775
132 frame 106507 106508
18 1
Drive Lock Washer (IEC Only)
90 frame J102282 J103847
100/112 frame 105757 105758
132 frame 106503 106504
19 1
Drive Flat Washer (IEC Only)
90 frame 105722 105772
100/112 frame J101360 106200
132 frame 106509 106510
20* 4
Motor Adapter Flange Bolt (for IEC with B14 flange and 143/145TC Frames Only)
90 frame 108029 106513
100/112 frame 105589 106514
132 frame 105774 105775
143/145TC frame J101000 107740
21* 4
Motor Adapter Lock Washer (for IEC with B14 flange only)
90 frame J102282 J103847
100/112 frame J102282 J103847
132 frame 105757 105758
22* 4
Motor Adapter Flat Washer (for IEC with B14 flange only)
90 frame J101293 J103845
100/112 frame J101293 J103845
132 frame N/A N/A
*Customer must supply motor adapter flange bolt, lock washer and flat washer for IEC frame pumps with B5 flanges.
