12 3
All equipment is potentially hazardous. There is no substitute for a cautious, safe-minded operator who
recognizes potential hazards and follows reasonable safety practices.
When the use of hand tools is required to perform any part of assembly, installation, adjustment, maintaining,
repairing, removal, or moving the implement, be sure the tools used are designed and recommended by the
tool manufacturer for that specific task.
Personal protection equipment including safety glasses, safety shoes, and gloves are recommended during
assembly, installation, operation, adjustment, maintaining, repairing, removal, or moving the rear blade.
Always use two people to handle heavy, unwieldy components during assembly, installation, removal, or
moving the rear blade.
Never place any part of your body where it would be in danger if movement should occur during assembly,
installation, operation, maintaining, repairing, removal, or moving the implement.
Never place yourself between the tractor and implement while implement is in operation.
Do not work under a raised implement unless it is securely blocked or held in position. Do not depend on the
tractor hydraulic system to hold the implement in place.
A heavy load can cause instability of the tractor. Use extreme care during travel. Slow down on turns and
watch out for bumps. The tractor may need front counter-weights to counter-balance the weight of the
implement.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this
equipment. Consult your doctor about operating this machine while taking prescription medications.
Do not allow others to ride on the tractor with an operator. Riders are subject to injury such as being struck by
foreign objects or being thrown off. Riders obstruct the operator’s view resulting in unsafe operation. Never
allow anyone to ride on the implement!
Before you operate the rear blade, check over all pins, bolts and connections to be sure all are securely in
place. Replace any damaged or worn parts immediately.
Do not allow anyone who is not familiar with the safety rules and operation instructions to use this rear blade.
Never allow children to operate or be around equipment.
Use stabilizer bars, adjustable sway chains, or sway blocks on your tractor lift arms to keep the rear blade from
swinging side to side. Adjust as tightly as practical for best performance.
S A F E T Y I N S T R U C T I O N S (continued)
REF. PART NO.
NO. NO. DESCRIPTION REQ.
1 346801 Mount Frame 1
N/S 346901 Moldboard Assembly 1
N/S 350029 Cutting Edge 1
4 2503045 Plow Bolt 5 / 8 ” – 11NC x 1 1 / 2 ” 9
5 2502007 Lockwasher 5 / 8 ” 9
6 2500013 Nut 5 / 8 ” – 11NC Full Hex 9
7 346810 Tilt Adjustment Bolt 2
8 346812 Tie Plate 2
9 2502001 Lockwasher 3 / 4 ” 2
10 2500002 Nut 3 / 4 ” – 10NC Full Hex 2
11 590108 Lift Pin (AK-578) 2
12 350030 Adjustment Pin 1
13 101033 Decal – Caution, Safe Operating Practices 1
14 101055 Decal – Warranty Notice 1
UB-750-T
UTILITY BLADE
REF. PART NO.
NO. NO. DESCRIPTION REQ.
1 346801 Mount Frame 1
N/S 347001 Moldboard Assembly 1
N/S 350105 Cutting Edge 1
4 2503045 Plow Bolt 5 / 8 ” – 11NC x 1 1 / 2 ” 10
5 2502007 Lockwasher 5 / 8 ” 10
6 2500013 Nut 5 / 8 ” – 11NC Full Hex 10
7 346810 Tilt Adjustment Bolt 2
8 346812 Tie Plate 2
9 2502001 Lockwasher 3 / 4 ” 2
10 2500002 Nut 3 / 4 ” – 10NC Full Hex 2
11 590108 Lift Pin (AK-578) 2
12 350030 Adjustment Pin 1
13 101033 Decal – Caution, Safe Operating Practices 1
14 101142 Decal – Warranty Notice 1
UB-850-T
UTILITY BLADE
