Page 17
Chapter 1
11
Left View
Right View
9
Wireless
communications
button/indicator
Press to enable/disable Wireless function. Lights to
indicate the status of wireless LAN communications.
(manufacturing option)
10
N/A
Latch
Locks and releases the lid.
#
Icon
Item
Description
1
N/A
Optical drive
Internal optical drive; accepts CDs or DVDs
2
N/A
Optical disk access
indicator
Lights up when the optical drive is active.
3
N/A
Optical drive eject button Ejects the optical disk from the drive.
4
N/A
Emergency eject hole
Ejects the optical drive tray when the computer is
turned off.
#
Icon
Item
Description
1
N/A
PC Card slot eject
button
Ejects the PC Card from the slot.
2
PC Card slot
Connects to one Type II CardBus PC Card.
3
Two USB 2.0 ports
Connect to Universal Serial Bus (USB) 2.0 devices
(e.g., USB mouse, USB camera).
"Launch keys" on page 10
#
Icon
Item
Description
#
Item
Description
Note:
#
Item
Description
#
Icon
Item
Description
#
Icon
Item
Description
#
Item
Description
#
Icon
Item
Description
#
Icon
Item
Description
