Fairbanks Portable Axle Load Scale - Manual (Page 8)

D. Ramp Installation
The ramps are used in combinations in specific applications.
1. Each ramp has two (2) bolt down tabs as part of the ramp.
2. Place the ramp against the the platform frame.
3. The ramp should be made stable and level.
Shims are not included with the ramps and must be supplied.
4. Bolt the ramps to scale frame using 3 /
4
” hardware.
5. Drill and anchor the ramp(s) using the supplied 3 /
4
” wedge anchors.
6. No more than two (2) ramps, located on opposite sides of the platform, may
be installed.
E. Instrument Installation
The platform is shipped fully assembled and wired. The interface cable to the
indicator is as follows:
L/C Wire Color Function Analog Instrument
Black (-) Excitation (-) Excitation
Green (+) Excitation (+) Excitation
Yellow Shield Shield
White (+) Signal (+) Signal
Red (-) Signal (-) Signal
Refer to the proper indicator service manual for proper installation, programming, and
calibration of the indicator.
