Section 4: Operation
10/13 21 51287 Rev. 2
7. Press the key to go up a value or press the key to go down a value
until the required value is reached.
8. Press the key to change to the next digit.
9. Repeat this procedure until the required piece weight is displayed.
10. To accept the new value press key.
11. The display shows the number of pieces currently on the weighing system.
You may make a printout and add up the weights. A special printout will be made
which includes the piece weight sampled and the number of pieces.
Return to the normal weighing mode is accomplished by pressing the key for 1
second. Upon the return to normal weighing mode, the piece count total will be lost.
4.4.9. TOTALING
The indicator offers the possibility to add weighments and display the total weight.
When a tare weight is active, the net weight is added automatically.
1. Load the system with the weight that should be added.
2. Press the key to add the weighed load to the total weight.
3. The display shortly shows the message ADDED and then automatically
returns to the weighing mode.
4. If a printer is installed, a printout will be made
5. The gross, net and tare weights are totaled.
6. No weight can be recorded twice. The system needs to be returned to the net
zero-range before another weight can be added up.
7. The subtotal can be checked by pressing the key for 3 seconds.
8. The display shows the net total weight and the number of weighments totaled
thus far repeatedly for 3 seconds.
9. If the key is pressed shortly during this period, the total is printed out (if
option is installed) and reset to 0.
