Section 3: Parts
Parts List
Key #
BPP1000
Part #
BPP2000
Part # Description
55017 BPP1000 Series, 24" x 21", 1K x .5, NTEP, Portable Beam
55789* BPP2000 Series, 24" x 31", 2K x 1, NTEP, Portable Beam
1 71622 78796* Set of Pillar Rods
2 58933 77228* Pillar
3 95847 Cover Assembly, Platform
4 95848 Frame
5 95855 Cotter Pin
6 58937 Bearing, Platform
7 95856 Screw, Phillips Head
8 95857 Screw, Allen
9 95858 Level, Bubble
10 95859 Pin, Corner Loop
11 71623 Loop, Corner
12 71624 Bearing, Corner Loop
13 71625 Cotter Pin
11, 12, 13 58938 Corner Loop Assembly
14 95867 Nut, Hex
15 95868 Bolt, Hex Head
16 95869 Wheel, 5" Diameter
17 71628 Cotter Pin
18 71629 Washer, Flat
19 71630 Axle
24 95861 Pivot
25 72948 Lever Assembly, Short
26 58939 Center Connection Assembly (26, 27, 28, 29, 32)
27 Clip, Center Connection
28 Link, Center Connection
29 Cotter Pin
30 95862 Pivot
31 95863 Pivot
32 75712* Upper Bearing, Center Connection
33 72947 75713* Long Lever Assembly
34 95864 Long Lever Tip Pivot
35 58934 Steelyard Rod Assembly
xxxxx* Indicates a part number for the BPP2000.
